To attach the top handle with URSA Viewfinder
1
Top handle URSA Viewfinder cap
2
Place your URSA Mini on a flat, stable surface
so you can access the top of your camera. Remove the URSA Viewfinder cap from the
base of the handle by gently lifting its arm
away from the side of the handle and pulling
the cap from the hole.
3
URSA Viewfinder adapter plate Thumbscrew for adjusting the
optional URSA Viewfinder position
2 x 1/4” socket head screws for
mounting handle to camera
4
Fasten the URSA Viewfinder adapter plate to the
handle using the 4 x M3 screws with a 2.5mm
Hex key driver. Fasten the handle to any two of URSA Mini’s top
1/4” mounting points using the two supplied 1/4”
screws with a 3/16” Hex key driver. URSA Mini’s
rear two mounting points are recommended for
most situations, but you can choose any pair for
better weight balance when using large lenses.
Avoid over-tightening the screws as it may
damage the screw threads.
The hole inside the front of the handle is used
with the thumb screw when attaching and
adjusting the URSA viewfinder. For information
on how to attach the URSA Viewfinder to the
top handle, refer to the ‘Blackmagic URSA
Viewfinder’ section in your URSA manual.
