Page 26: Projector/display connections -10, Preliminar y, Operation, features, and cabling, cont’d
Operation, Features, and Cabling, cont’d
MLC 104 Plus Series • Operation, Features, and Cabling
2-10
PRELIMINAR
Y
Right/rear panel and cabling
RUN
100
2
3
GROUND
1
IR IN
GROUND
IR OUT
CM
SCP
GROUND
GROUND
Tx
Rx
DISPLA
Y
RS-232/IR
LAN
PRESS
TAB
WITH
TWEEKER
TO REMO
VE
A B
MLS
PWR
RS-232 12V
DIGIT
AL
I/O
A B C D E
COMM LINK
+V OUT
GROUND
Tx
Rx
+12V IN
6
4
5
3
1
2
4
5
3
1
2
Rear Panel
MLC 104 IP Plus
Right Side Panel
(IP models
only)
a
Display control (Display RS-232/IR) port
b
c
Digital I/O ports (24 V, 1 A) (
page 2-14
and
“Using Digital Inputs”
and
in chapter 5)
d
MLS connector
(page 2-17)
e
PWR (power) connector
(page 2-20)
f
LAN (IP) connector and LEDs
— IP models only
Projector/display connections
a
Display control (Display RS-232/IR) port (-5 VDC to +5 VDC) —
From this port, commands from a projector driver or user-defined command
strings entered via Global Configurator can be sent to the display device.
Connect a cable between the projector or display and the left three poles
(TX, RX, Ground) of this 3.5 mm direct insertion captive screw connector for
bidirectional RS-232 control. The IR Out and Ground pins (the right two
poles
) can be used for one-way infrared signal output to control the display/
projector or some other device, such as a VCR or DVD player. Use the
following illustrations as a wiring guide.
Projector/
Panel Display
MLC 104 Plus Series
Right Side Panel
To a Source’s
IR Receiver
Ground ( )
Receive (Rx)
Transmit (Tx)
Ground ( )
Receive (Rx)
Transmit (Tx)
Bidirectional RS-232
Ground ( )
IR Signal
Unidirectional IR Output
via White Striped Wire
Strip
wires
3/16”
(5 mm)
max.
NOTE
The connector accepts one wire
per pole. You may need to
splice projector and IR Emitter
ground wires to a single wire
that is inserted into this port.
IR Emitter
100'
(30.5 m)
G
RO
U
N
D
IR
O
U
T
Tx
R
x
DISPLAY
RS-232/IR
Wiring for RS-232 display control and IR source device control
