Extron Electronics MLC 104 Plus Series - Manual (Page 48)

Software-based Configuration and Control, cont’d
MLC 104 Plus Series • Software-based Configuration and Control 3-8
PRELIMINAR
Y
or
•
Click on the Start menu,
click on Settings (if needed), click on Control Panel to open the Control
Panel window, then double-click on Network and Dial-up Connections
(Windows 2000) or Network Connections (Windows XP, shown below).
2. Right-click on Local Area Connection, then select Properties.
3. Select Internet Protocol (TCP/IP)
and click on the Properties button
(shown at right). If Internet Protocol
(TCP/IP)
is not on the list, it must be
added (installed). Refer to the
Microsoft Windows user’s manual or
the Windows online help system for
information on how to install the
TCP/IP protocol.
4. Write down the PC’s current IP
address and subnet mask below.
If your PC is set to “Obtain an IP
address automatically,” make a note
of that, instead. You will need to
restore these settings to the PC later.
IP address:
. . . .
Subnet mask:
. . . .
