Special Applications, cont’d
MLC 104 Plus Series • Special Applications 5-30
PRELIMINAR
Y
2. In the IP Link tree view window, click on the MLC to be configured.
3.
Configure the MLS port with the correct driver.
a.
Click on MLS Port. The MLS Port tab displays in the right side of the
window.
b. Click the Disable MLS support (Enable serial driver support) radio
button. If the Confirm MLS Port Change window appears, click OK.
c. Click on the Serial Configuration tab.
d. Select the device type (display or video projector) and manufacturer.
e. Locate and select (click on) the display or projector’s model name in the
Available Drivers area.
f. Click Add Driver. The display’s name appears in the Added Drivers
field, and the commands available in its driver appear in the
GlobalViewer area at the bottom of the window.
