SIS ™ Programming and Control, cont’d
MLC 104 Plus Series • SIS Programming and Control 4-18
PRELIMINAR
Y
Command/r
esponse table for SIS commands (continued
)
Command
ASCII (T
elnet
)
(host to MLC
)
URL Encoded (W
eb
)
(host to MLC
)
Response (MLC to host
)
Additional description
Query updated firmwar
e version
4Q
4Q
X1!
(kernel version–model description–date time of upload)
]
or
V
er04*
X1!
(kernel version–model description–date time of upload)
]
Use this command to find out which version of the firmwar
e, if any
, was uploaded into
the contr
oller after it left the factory
Example:
4Q
4Q
1.01*(1.65-MLC104IP
-Thu, 28 Jun 2007 00:35:39 GMT)
]
In this example the curr
ent firmwar
e version
is 1.01, the IP
Link kernel version is 1.65, for
the MLC 104 IP
Plus, dated 28 June, 2007.
N
Responses to commands differ depending on which, if any
, verbose r
esponse mode the MLC is in.
See the CV command (
E
X2@
CV
}
) under IP setup commands later in this
table.
Query FPGA
version
32Q
32Q
X1!
]
Show the field-pr
ogrammable gate array
(FPGA) firmwar
e version to two decimal
places (x.xx).
Request the MLC’s part number
N
N
60-818-00
]
or
60-1014-00
]
or
Pno60-818-00
]
or
Pno60-1014-00
]
Show the MLC’s part #. IP
models r
espond with 60-818-00,
the MLC
104
Plus shows 60-1014-00.
Request
A/V input number
14
I
I
Chn
X20)
]
Show which input is active (selected). X20)
is the input number
.
N
The MLC r
esponds with an E14 err
or if no input buttons ar
e set up for firmwar
e contr
ol (input switching).
Request the model name
1I
1I
MLC 104 IP
PLUS
]
or
Inf01*MLC 104 IP
PLUS
]
MLC 104 IP
Plus.
Request the model description
2I
2I
MLC 104 IP
PLUS
]
or
Inf02*MLC 104 IP
PLUS
]
MLC 104 IP
Plus.
Request system memory usage
3I
3I
# bytes used out of # of kbytes
]
or
Inf03*# bytes used out of # of kbytes
]
Show amount of memory used and total available memory for system operations.
Request user memory usage
4I
4I
# bytes used out of # of kbytes
]
or
Inf04*# bytes used out of # of kbytes
]
Show amount of user memory used and total available user memory
.
Example:
4I
4I
217856 Bytes Used out of 7232 KBytes
Request status of attached har
dwar
e
32I
32I
P1##•P2##•K1##•K2##•K3##•K4##•S
]
