Operation 3. AUTO Mode
TP1 Rev.5 85
3.6.6 Export Files
Exports “Prg”, “Inc” and “Pts” files in projects in the Controller to the USB memory.
(1) Insert the USB memory into the Controller.
(2) In the [Program Mode] screen, move the cursor to [5 Export File...], and press the
key.
(3) The following screen appears.
Move the cursor to the file to export, and press the key.
(4) The following screen appears. Press the key.
When key is pressed without specifying a folder, the backup file is stored
directly in the USB memory. For prcedure to specify th folder, refer to (5).
(5) The following screen appears.
Move the cursor to export and press the key.
Displays the hierarchy one level below the selected folder.
Displays the hierarchy one level above the selected folder.
) TIP
