Operation 2. TEACH Mode

TP1 Rev.5

2.3 Changing Jog Distance Data

This section indicates settings in the [Jog Distance] screen.

Press the key in the [Jog&Teach] screen.
The following screen appears.

When a value has been changed, press the key to apply the value, and be sure to
press the key to save the settings.

2.3.1 Changing Distance Data

Set the distance for each joint.

(1)

Move the cursor to [Distance], press the key to select the distance (Long,

Medium, Short) that is to be changed.

(2)

Move the cursor to each joint, and set the value.

2.3.2 Return Data to Defaults

Press the key to return jog distance data to their defaults.
