HEIDENHAIN iTNC 530 709
14.1 Gener
a
l User P
a
ra
met
e
rs
Probing feed rate for second measurement
with TT 120, stylus shape, corrections in
TOOL.T MP6507
Calculate feed rate for second measurement with TT 130,
with constant tolerance: +0
Calculate feed rate for second measurement with TT 130,
with variable tolerance: +1
Constant feed rate for second measurement with TT 130: +2
Maximum permissible measuring error
with TT 130 during measurement with
rotating tool
Required for calculating the probing feed rate in
connection with MP6570
MP6510.0
0.001 to 0.999 [mm] (recommended input value: 0.005 mm)
MP6510.1
0.001 to 0.999 [mm] (recommended input value: 0.01 mm)
Feed rate for probing a stationary tool with
the TT 130 MP6520
1 to 3000 [mm/min]
Radius measurement with the TT 130:
Distance from lower edge of tool to upper
edge of stylus MP6530.0 (traverse range 1) to MP6530.2 (traverse range 3)
0.001 to 99.9999 [mm]
Set-up clearance in the tool axis above the
stylus of the TT 130 for pre-positioning MP6540.0
0.001 to 30 000.000 [mm]
Clearance zone in the machining plane
around the stylus of the TT 130 for pre-
positioning MP6540.1
0.001 to 30 000.000 [mm]
Rapid traverse for TT 130 in the probe cycle MP6550
10 to 10 000 [mm/min]
M function for spindle orientation when
measuring individual teeth MP6560
0 to 999
-1: Function inactive
Measuring rotating tools: Permissible
rotational speed at the circumference of the
milling tool
Required for calculating rpm and probe feed
rate
MP6570
1.000 to120.000 [m/min]
Measuring rotating tools: Permissible
rotational rpm MP6572
0.000 to 1000.000 [rpm]
If you enter 0, the speed is limited to 1000 rpm
3-D Touch Probes
