626 12 Test Run and Program Run
12.1 Gr
aphics
12.1 Graphics
Function
In the program run modes of operation as well as in the Test Run
mode, the TNC provides the following three display modes: Using soft
keys, select whether you desire:
„ Plan view
„ Projection in 3 planes
„ 3-D view
The TNC graphic depicts the workpiece as if it were being machined
with a cylindrical end mill. If a tool table is active, you can also simulate
the machining operation with a spherical cutter. For this purpose,
enter R2 = R in the tool table.
The TNC will not show a graphic if
„ the current program has no valid blank form definition
„
no program is selected
With MPs 7315 to 7317 you can have the TNC display a graphic even
if no tool axis is defined or moved.
Using the new 3-D graphics you can now also graphically
display machining operations in the tilted working plane as
well as multi-sided machining operations, provided that
you have already simulated the program in another view.
The MC 422 B hardware is required to be able to use this
function. In order to increase the speed of the test
graphics on older hardware versions, bit 5 of MP7310
should be set to 1. This deactivates functions which were
implemented specifically for the 3-D graphics.
The TNC graphic does not show a radius oversize DR that
has been programmed in the TOOL CALL block.
