FN14: ERROR: Displaying error messages
With the function FN14: ERROR you can call messages under
program control. The messages are predefined by the machine tool
builder or by HEIDENHAIN. Whenever the TNC comes to a block with
FN 14 in the Program Run or Test Run mode, it interrupts the program
run and displays a message. The program must then be restarted. The
error numbers are listed in the table below.
Example NC block
The TNC is to display the text stored under error number 254.
Error message predefined by HEIDENHAIN
Range of error numbers Standard dialog text
0 ... 299 FN 14: Error code 0 .... 299
300 ... 999 Machine-dependent dialog
1000 ... 1099 Internal error messages (see table
at right)
180 FN14: ERROR = 254
Error number Text
1000 Spindle?
1001 Tool axis is missing
1002 Tool radius too small
1003 Tool radius too large
1004 Range exceeded
1005 Start position incorrect
1006 ROTATION not permitted
1007 SCALING not allowed
1008 MIRRORING not allowed
1009 Datum shift not permitted
1010 Feed rate is missing
1011 Entry value incorrect
1012 Wrong sign programmed
1013 Entered angle not permitted
1014 Touch point inaccessible
1015 Too many points
