Display panel stop bracket – Gasboy Atlas Commercial Series User Manual
Page 89
Item #
Part Description
Current Part
Previous Part
Quantity
1
PCB, LCD Main Display
T17701-G1
-
2 per meter
2
Reflector, Backlight 9
T17622-G9
-
2 per meter
3
Display Panel Single
M05041B001
-
1 per side
Display Panel Dual
M05040B001
-
1 per side
4
Manager Keypad
T17549-G1
-
1 per unit
PT-1949D Gasboy Atlas™ Pump and Dispenser Illustrated Parts Manual · March 2010
Page 83
Display Panel Stop Bracket
Retail Printed Circuit Boards
Display Panel Stop Bracket
1
Item #
Part Description
Current Part
Previous Part
Quantity
1
Bracket, PC Board Support
M05611A002
M05611A001
1
T17549-G1
4
