Item # Part Description Current Part Previous Part Quantity
1 AC Junction Box, Mach 8753E 003116 - 1
2 AC Junction Box, Cover 003117 - 1
3 AC Conduit and Wire Assembly M05686A002 (see note 1) - 1
M05686A003 (see note 2) - 1
4 Conduit AC Single M05692A002 (see note 1) - 1
M05692A003 (see note 2) - 1
5 Bolt Hex HD Finished 1/4 - 20 X 0.88 K56467 - 8
6 Bolt Hex HD Finished 5/16 - 18 X 0.75 Q10624-01 - 1
7 Bracket Junction Box, AC M05575B001 - 1
8 Elbow, Conduit 1/2 X 90 Deg. 025045 - 2
9 Expansion Union (Conduit) N16289-20 - 3
10 Male Conduit Enlargers (NPT) K81090-20 - 2
11 Nut 10-32 Ground Screw 067500 - 1
12 Pipe Plug C-Sunk 1/2 K43850 - 6
13 Pipe Plug C-Sunk 3/4 K57624 - 1
14 Screw, 10-32 X 3/8 BND HD SLT 052976 - 1
15 Screw, TF, Hex Washer HD M8 X 18 M00417B009 - 2
16 Terminal, Wire Ring 064874 - 1
17 Washer 5/16 SAE-N 0.69 X 0.34 X 0.06 K65235-33 - 1
18 Lock Washer, 5/16 PL K73278-28 - 1
Notes: 1) This part is for 9850KXTW2.
2) This part is for 9850KXTW1 and 9850KXTW1-M. Units built after August 2007.
Ultra-Hi Junction Box and Conduit Section AC Junction Box and Conduit
Page 144 PT-1949D Gasboy Atlas™ Pump and Dispenser Illustrated Parts Manual · March 2010
9850KXTW1, 9850KXTW1-M, 9850KXTW2
