Sheathing, Doors, Bezels Lower Doors
Page 8 PT-1949D Gasboy Atlas™ Pump and Dispenser Illustrated Parts Manual · March 2010
Top Panels - Painted
Note: To order a painted panel, you must include the part number and the paint code. Refer to
“Paint Codes” on page 4 .
Unit Description Part Description Current Part Previous Part Quantity
Standard Electronic and Mechanical Units (Painted) Top Sheath - Standard (Painted) M04887B011 - 1 per unit
Electronic units with TopKat option (Painted) Top Sheath - TopKat (Painted) M04887B012 - 1 per unit
Mechanical One- sided Units with Electrical Keytrol
Option (Painted)
Top Sheath - Electrical Keytrol,
Single (Painted)
M04887B013 - 1 per unit
Mechanical Dual-sided Units with Electrical Keytrol
Option (Painted)
Top Sheath - Electrical Keytrol,
Dual (Painted)
M04887B014 - 1 per unit
Lower Doors
Select appropriate door or door part for your unit from the table below.
Note: All units have two doors
Unit Description Door Description Part Number Quantity per Unit
Mechanical Model Lower, Stainless Steel M06715B001 2
Lower Panel, Painted M06715B101 2
Electronic Model, Side-load Lower Panel, Stainless Steel M06715B002 2
Lower Panel, Painted M06715B102 2
Electronic Model, Front-load Single-sided Lower Panel w/Boot cutout, Stainless Steel M06715B003 1
Lower Panel, No Cutout, Stainless Steel M06715B002 1
Lower Panel w/Boot cutout, Painted M06715B103 1
Lower Panel, No Cutout, Painted M06715B102 1
Electronic Model, Front-load Dual-sided Lower Pane, Stainless Steel M06715B003 2
Lower Panel, Painted M06715B103 2
.
Note: All Electronic models using the above doors must also have two Rain Guard Air Gap
Baffle Plates M06690B001. Refer to “Air Gap Hardware and CD Module Housing” on
page 49 .
Additional Door Parts
Part Description Part Number Quantity per Door
Nozzle Boot Cover, Stainless Steel (Front-load only) M04832B001 1
Nozzle Boot Cover, Painted (Front-load only) M04832B101 1
Panel Lock and Key Kit K34673 1
