Introduction How to Use Your Manual
Page 2 PT-1949D Gasboy Atlas™ Pump and Dispenser Illustrated Parts Manual · March 2010
Quantity
Quantity is per assembly shown. Quantity per unit will vary depending on unit configuration.
Use specification in parts table to obtain fasteners locally. Most kits contain hardware required
for installation.
Bulleted Items (Located under Description)
These items are directly related to the previous part number listed. Parts are generally used for
mounting or fastening hardware.
Related Documents
The following documents provide additional information:
Document
Number
Title GOLD Library
PT-1950 Gasboy Atlas Recommended Spare Parts Parts Manual
When Ordering Parts
Keep the following items in mind when ordering Gilbarco ® parts:
1 Furnish the model number, date code, and original options. This information is stamped on a
serial plate located on the rail
in the lower frame section. See Figure 1 .
2 Provide the following information:
• Part number
• Quantity of the part needed
• Description of part
• Color, graphics, and other details needed for order entry items.
Note: Order entry item: An item that can be ordered individually using its individual part
number (not a part that is available only as part of a kit).
Figure 1: Serial Plate
Serial
Number
Unit
Type
Options
Model
Number
