Ultra-Hi Hydraulics Section
Satellite Piping for 9850KTW3 Combo Pump and 9850KXTW3 Combo Dispenser
Page 138 PT-1949D Gasboy Atlas™ Pump and Dispenser Illustrated Parts Manual · March 2010
Note: All parts for combos are same as standard units except for the addition of satellite inlet
and discharge piping.
Pump
Lower
Frame
Satellite
Inlet and
Discharge
Piping
AC
Junction
Box
Meter
and
Pulser
Pump
Upper
Frame
Air Gap
AC
Junction
Box
Air Gap
Meter
and
Pulser
Dispenser
Upper
Frame
Satellite
Inlet and
Discharge
Piping
9850KTW3 Combo Pump
9850KXTW3 Combo Dispenser
Dispenser
lower
Frame
