PT-1949D Gasboy Atlas™ Pump and Dispenser Illustrated Parts Manual · March 2010 Page 51
Lower Pulser Seal Assembly - 8800, 9840, 9852, 9853 Air Gap - 8800, 9100, 9840, 9852/53
Lower Pulser Seal Assembly - 8800, 9840, 9852, 9853
Item # Description Current Part Previous Part Quantity
Assembly, Lower Pulser Seal M03023A001 - 1
1 • Assembly Plate Lower Pulser M03015A002 - 1
2 • Fastener Push-on Prong - Slotted M03025B001 - 1
3 • Link, Pulser Drive M00136B002 - 1
4 • Roll Pin 5/64 X 3/4 SSTL K78378-47 - 1
5 • Shaft Pulser M00137B004 - 1
6 • Swivel Ball K93546 - 1
7 • Truarc Retaining Ring K76238-22 - 2
5
2
7
4
3
6
1
