PT-1949D Gasboy Atlas™ Pump and Dispenser Illustrated Parts Manual · March 2010 Page 17
Hose Hanger and Hose Retriever Nozzle Boots, Hose Hook, and Internal Hose Retrievers
Internal Hose Retriever - 3/4-inch
Item # Part Description Current Part Previous Part Quantity
1 Assembly, Retriever, and Cable N20545-02 - 1
2 Grommet Hose Cable 45 Degrees R18453-01 - 1
3 Nut, Hex 1/4-20 K01941 - 1
4 Clamp, Hose (Inner Half) 3 N18319-03 - 2
5 Nut Hex Keps w/Ext LW 4 Q12068-05 - 1
6 Clamp, Hose, and Cable N18320-21 - 2
7 Ring, Retaining K85573-01 - 1
8 End Cable Block K86055-01 - 1
9 Tie Clamp Q13641-01 - 1
10 Screw Cap OV Flst 1/4-20 K04585 - 1
11 Washer Lock Internal TH 1/4 X 0.018 K50411-25 - 1
Internal Hose Retriever - 1-inch
Item # Part Description Current Part Previous Part Quantity
1 Assembly, Retriever, and Cable N20545-02 - 1
2 Grommet Hose Cable 45 Degrees R18453-01 - 1
3 Nut, Hex 1/4-20 K01941 - 1
4 Screw Phl Pnh 10-32 X 0.50 Q11270-174 - 1
5 Nut, Screw, Clamp, Hose K75766 - 1
6 Adapter Cable K85940 - 1
7 Assembly, Hose Clamp 1-1/2” N15680-01 - 1
