Base Electronics
Page 56 PT-1949D Gasboy Atlas™ Pump and Dispenser Illustrated Parts Manual · March 2010
Base Electronics
“Commercial PCBs (Non-Ultra-Hi)”
Power Supply
“Commercial PCBs (Non-Ultra-Hi)”
on
Pulser Assembly
2
1
3
Item #
Description
Current Part
Previous Part
Quantity
1
Assembly, Pulser
M04011B001
-
1
2
Assembly, Pulser Supt Bracket
M04485A001
-
1
3
Spring Retainer Pulser Shaft
M01207B001
-
1
