Ultra-hi dispenser lower hydraulic upper frame – Gasboy Atlas Commercial Series User Manual
Page 125
PT-1949D Gasboy Atlas™ Pump and Dispenser Illustrated Parts Manual · March 2010
Page 119
Ultra-Hi Dispenser Lower Hydraulic Upper Frame
Ultra-Hi Frame Section
Ultra-Hi Dispenser Lower Hydraulic Upper Frame
Note: Units built after 12/11/2008.
2
3
1
Item #
Part Description
Current Part
Previous Part
Quantity
1
Rail Meter Support
M05537B001
-
2
2
Screw, Metric M8 X 18
M00417B009
-
16
3
Plate Inlet Ftg Support
M05538B001
-
1
