Comtech EF Data DT-4500-A Series - Manual (Page 94)

DT-4500-A Series Downconverters Revision 1
Ethernet-based Remote Product Management MN-DT4500A
6–8
6.4.3.4 Drop-down lists
A drop-down list lets you choose from a list of selections. Left-click
the drop-down button to open the list. Then, left-click on an item to
select that choice.
6.4.3.5 Text or Data Entry
Text boxes let you type data into a field. An action button may be
associated with a single text box, or a group of text boxes. For any
text box, left-click anywhere inside the box, type the desired
information into that field, and be sure to press [ENTER] when done.
Click the related action button to save the data.
If you edit any field, make sure to click the action button before you leave the
page. If you go to another page without first clicking the action button, your
changes are not saved.
6.4.4 45xxA Web Server Interface Menu Tree
The 45xxA Web Server Interface features four navigation tabs (shown in blue) located at the top
of each page. Nested page hyperlinks (gray) grant access to individual Web pages.
Home Admin Config Status
Home Access Converter Summary
Contact SNMP Ref Faults
Support Pre-selects
Utility
Redundancy
Click any tab or hyperlink to continue.
