Comtech EF Data DT-4500-A Series User Manual
Page 86
DT-4500-A Series Downconverters
Revision 1
Front Panel Operation
MN-DT4500A
5–18
UTILITY: FIRMWARE INFO
Firmware Info: BOOTROM
IMAGE#1 IMAGE#2
Use the
◄ ►
arrow keys to select BOOTROM, IMAGE#1 or IMAGE#2, and then press ENTER to
view the information.
The BOOTROM screen displays information similar to the example that follows:
Bootrom: FW-0000200
X.X.X MM/DD/YY
For IMAGE#1 and IMAGE#2, each image is further broken down as follows (where IMAGE#X
denotes IMAGE#1 or IMAGE#2):
IMAGE#X: Bulk APP FPGA
Use the
◄ ► arrow keys to select Bulk, App, or FPGA, and then press ENTER. The screens display
information in a format similar to the examples that follow:
Bulk#X: FW-0000202
X.X.X MM/DD/YY
App#X: FW-0000203
X.X.X MM/DD/YY
FPGA#X: FW-0000204
X.X.X MM/DD/YY
UTILITY: Firmware SELECT
Current Active Image: #1
Next Reboot Image: #1 #2
The top line shows the Current Active Image. From the bottom line, select the Next Reboot
Image (i.e., the image that will be active the next time the unit is rebooted) as #1 or #2 using
the
◄ ►
arrow keys. Press ENTER when done.
If the image selected is already designated as the Next Reboot Image, the following message
displays:
THAT IMAGE IS ALREADY
CURRENT. NO CHANGE MADE.
