DT-4500-A Series Downconverters Revision 1
Installation MN-DT4500A
2–2
This equipment contains parts and assemblies sensitive to damage by Electrostatic
Discharge (ESD). Use ESD precautionary procedures when handling the equipment.
Once opened, inspect the shipment (Figure 2-1):
Step Task
1 Keep all shipping materials for storage or reshipment.
2 Check the packing list to ensure the shipment is complete.
3
Inspect the equipment for any possible damage incurred during shipment. Contact
the carrier and Comtech EF Data immediately to submit a damage report if damage is
evident.
4
Review this DT-4500A Series Downconverter Installation and Operation
Manual carefully to become familiar with operation.
5 Proceed to Sect. 2.2 Installing into a Rack Enclosure.
2.2 Installing into a Rack Enclosure
When mounting the DT-4500-A into a rack enclosure (Figure 2-2):
• PROPER GROUNDING PROTECTION IS REQUIRED. The equipment must be
connected to the protective earth connection at all times. It is therefore imperative
that the unit is properly grounded, using the ground stud provided on the unit rear
panel, during installation, configuration, and operation.
• PROPER AIR VENTILATION IS REQUIRED. In a rack system where there is high
heat discharge, provide forced-air cooling with top- or bottom-mounted fans or
blowers.
o
Make sure there is adequate clearance inside the enclosure, especially at
the side for air ventilation.
o
Air temperature inside the rack enclosure should never exceed 50 ° C
(122 ° F).
For information about custom rack enclosures, contact Comtech EF Data
Customer Support during normal business hours or visit Comtech EF Data’s Web
site (www.comtechefdata.com/support.asp).
