3.2.2.2 Switch Module IF, RF, and Loop Connectors
The IF and RF input and output connectors, and the Loop input and output connector types
vary depend on the band and impedence of the purchase unit. Modules are available for both
non-redundant (also referred to as single thread or standalone) and redundanct
configurations (see Appendix B. REDUNDANT SYSTEM OPERATION for the specific use of
these various switch modules).
The tables that follow provide a quick reference to the available switch modules and their
switching type, operating band, connector type, etc. for the DT-4500-A Series Downconverters
and UT-4500-A Series Upconverters. Contact Comtech EF Data for details and specifications
for the specific system module(s).
IOM Assemblies
CEFD P/N Impedance Comments
AS/0101-1 75 I/O, Type ‘SMA’
AS/0101-2 75 Non-switching, C-Band
AS/0101-9 50 Non-switching, C-Band
AS/0101-15 50 I/O, Type ‘SMA’
AS/0101-19 75 UT-4518-A w/isolator, Type ‘SMA’
AS/0101-21 50 UT-4518-A w/isolator
AS/0101-23 75 UT-4514F-A w/isolator, Type ‘SMA’
AS/0101-29 50 UT-4514F-A w/isolator, Type ‘SMA’
AS/0101-39 50 w/isolator, Type ‘SMA’
AS/0101-40 75 w/isolator
RSM Assemblies
CEFD P/N Impedance Comments
AS/0101-4 75 Switching, Ku-Band, down
AS/0101-6 75 Switching, C-Band, Type ‘N’
AS/0101-7 50 Switching, C-Band, Type ‘N’
AS/0101-16 50 I/O, Type ‘SMA’
AS/0101-20 75 Receive Switch, C-Band, RSM2
AS/0101-26 50 RSM2, Type ‘N’
AS/0101-37 50 w/isolator, Type ‘SMA’
AS/0101-38 75 w/isolator
TSM Assemblies
CEFD P/N Impedance Comments
AS/0101-3 75 Switching, Ku-Band, up
AS/0101-5 75 Switching, C-Band, up, Type ‘N’
AS/0101-8 50 Switching, C-Band, up
AS/0101-17 50 Switching, IF & RF, Type ‘SMA’
AS/0101-18 75 Switching IF & RF w/isolator
AS/0101-22 75 UT-4514F-A w/isolator, Type ‘SMA’
AS/0101-27 50 UT-4514F-A w/isolator, Type ‘SMA’
AS/0101-28 50 UT-4518-A w/isolator, Type ‘SMA’
AS/0101-42 75 DT-4513-A w/isolator, Type ‘SMA’
AS/0101-43 50 UT-4514F-A w/isolator
Table 3-8. DT-4500-A and UT-4500-A Available Switch Module Assemblies
