6.4.3 45xxA Web Server Interface Operational Features
6.4.3.1 Navigation
The 45xxA Web Server Interface features navigation tabs located at
the top of each page. After you click a navigation tab, you may click
an available page hyperlink.
This manual uses a naming format for all Web pages to indicate the depth of navigation needed
to view the subject page: “Top Level Tab | Web page hyperlink”.
For example: “Home | Support” is interpreted to mean “first click the top-level ‘Home’
navigation tab; then, click the ‘Support’ page hyperlink.
6.4.3.2 Page Sections
Each page features one or more sections. The title at the upper-left
corner of each page or page section provides indicates its
operational features. Each section can feature editable fields, action
buttons, and read-only displays that are specific to that section.
This manual explains the purpose and operation for each Web page on a per-page, per-section
basis.
6.4.3.3 Action Buttons
Action buttons are important in the Web Server Interface. Click an action
button to do one of these tasks:
• Reset changed parameters to remove unsaved changes.
• Permanently save changes.
• Refresh the page with current data.
If you edit a field, make sure to click the action button before you leave the page.
If you go to another page without first clicking the action button, your changes are
not saved.
