SNM-1002 LinkSync
 Modem
Revision 2
Installation MN/SNM1002.OM
2–9
2.3.5 External Reference (CP3)
CP3 is a BNC connector for an external reference. The input impedance is 75
Ω. For
normal operation, the reference signal is
≥
0 dBm.
2.3.6 AC Power Connector
The AC power is supplied to the SNM-1002 by a standard, detachable, non-locking,
3-prong power cord. Refer to the following listing for AC power specifications.
Input power 50W max.
Input voltage 90 to 264 VAC, 47 to 63Hz.
Note: Unit switches ranges automatically.
Connector type IEC
Fuse protection 1A slo-blo line and neutral fusing 5 mm type fuses.
2.3.7 DC Power - Optional
For DC supplied units, the DC Power is supplied by terminal lugs installed on the back
panel. Refer to the following table for specifications
Input power 50W max.
Input voltage 38 to 64 VDC.
Connector type Terminal Lug
Fuse protection 1A slo-blo 5 mm type fuses.
2.3.8 Ground Connector (GND)
A #10-32 stud on the rear panel of the modem is used for connecting a common chassis
ground among all equipment.
Note: The AC power connector provides the safety ground.
