SNM-1002 LinkSync
Modem
Revision 2
Remote Control Operation
MN/SNM1002.OM
A–27
Bulk
Consol.
Analog
Status
Command:
Response:
This command is similar to the 'BCS_' command, but returns
modem analog parameters. Additional status of new options
and features will always be appended to the end.
Where 'pn' is the last parameter returned.
Parameter
Number
Parameter Name
(Command Reference)
Description
1
2
3
4
5
6
Receive Signal Level
(ref. 'RSL_' command).
Raw BER
(ref. 'RBER_' command).
Corrected BER
(ref. 'CBER_' command).
Interface Read Error Status
(ref. 'IRES_' command).
EB/N0
(ref. 'EBN0_' command).
Buffer Fill Status
(ref. 'IBFS_' command).
p1 = xsnn.n, receive signal level in dBm.
p2 = xm.mE-ee.
p3 = xm.mE-ee.
p4 = tttt_xm.mE-ee.
p5 = xnn.n, EB/N0 in dB.
p6 = nn%, buffer fill status.
Note: Parameters 2 through 6 are dependent on carrier acquisition, if the decoder is not locked empty data blocks are returned (,,,,,).
Bulk
Consol.
Status
Command:
Response:
This command causes bulk modem status to be
returned. To reduce the length of the response,
message parameter data are returned without
identifiers. However, parameter identification can be
determined by order of return. Each status parameter is
terminated with a ',' (comma) except for the last
parameter which has the standard message
termination sequence ('cr''lf']). Most of the data returned
is formatted the same way as the single command
status request (refer to the appropriate portions of this
document in preceding sections). Additional
configuration status of new options and features will
always be appended to the end.
Where 'pn' is the last parameter returned.
