SNM-1002 LinkSync
 Modem
Revision 2
Remote Control Operation MN/SNM1002.OM
A–20
13. Data not returned if RX Channel #3 is disabled or
set for AUPC.
14. Data not returned if RX Channel #4 is
disabled or set for AUPC.
MODEM
Faults Status
(Summary)
Command:
Response:
>add/MFS_'cr'
DMD_xxx'cr'
MOD_xxx'cr'
TX_xxx'cr'
IRX_xxx'cr'
CEQ_xxx'cr'
BWAL_xxx'cr'’lf']
Demodulator (FLT/OK)
Modulator (FLT/OK)
Interface Transmit Side (FLT/OK)
Interface Receive Side (FLT/OK)
Common Equipment (FLT/OK)
Backward Alarms (FLT/OK)
Modulator
Status
Command:
Response:
>add/MS_'cr'
RF_xxx'cr'
MOD_xxx'cr'
SYN_xxx'cr'
DCS_xxx'cr'
ICH_xxx'cr'
QCH_xxx'cr'
AGC_xxx'cr'
SCT_xxx'cr'
EXT_xxx'cr'
CONF_xxx'cr'
SFLT_xx'cr''lf']
RF Output (ON/OFF) actual status not config
Module (OK/FLT)
IF Synthesizer (OK/FLT)
Data Clock Synthesizer (OK/FLT)
I Channel (OK/FLT)
Q Channel (OK/FLT)
AGC Level (OK/FLT)
Modem Reference PLL Lock (OK/FLT)
Modem Reference Activity (OK/FLT)
Configuration (OK/FLT)
Number of stored faults logged (0 to 10)
Demodulator
Status Command:
Response:
>add/DS_'cr'
MOD_xxx'cr'
CD_xxx'cr'
SYN_xxx'cr'
ICH_xxx'cr'
QCH_xxx'cr'
BERT_xxx'cr'
CONF_xxx'cr'
SFLT_xx'cr''lf']
Demod Module (OK/FLT)
Carrier Detect (OK/FLT)
IF Synthesizer Lock (OK/FLT)
I Channel (OK/FLT)
Q Channel (OK/FLT)
BER Threshold (OK/FLT)
Configuration (OK/FLT)
Number of stored faults logged (0 to 10)
Interface
Transmit
Side Status Command:
Response:
>add/ITXS_'cr'
DRP_xxx'cr'
TXD_xxx'cr'
PLL_xxx'cr'
CLK_xxx'cr'
TAC1_xxx'cr'
TAC2_xxx'cr'
CONF_xxx'cr'
SFLT_xx'cr''lf']
D&I Drop (OK/FLT)
Transmit Data/AIS (OK/FLT)
Transmit Synthesizer PLL Lock (OK/FLT)
Selected Transmit Clock Activity (OK/FLT)
Transmit Audio Clip Channel #1 (OK/FLT)
Transmit Audio Clip Channel #2 (OK/FLT)
Configuration (OK/FLT)
Number of Stored Faults Logged (0 to 10)
