XCVR_STATUS Register
Table 5-4: HMC Controller IP Core XCVR_STATUS Register at Offset 0x08
Individual transceiver status in HMC link, ordered by transceiver channel.
Bits Field Name Type Value on
Reset
Description
31:16 Reserved RO 0x0001
15:8 (half-
width IP
core)
Reserved RO 0x00
7:0 (half-
width IP
core)
CDR Lock
RO 0x00
Each bit indicates whether the CDR for the
corresponding transceiver channel has locked to
the received data.
15:0 (full-
width IP
core)
CDR Lock
RO 0x00
00
LANE_STATUS Register
Table 5-5: HMC Controller IP Core LANE_STATUS Register at Offset 0x0C
Individual lane status in HMC link, ordered by transceiver channel.
Bits Field Name Type Value on
Reset
Description
31:24
(half-
width IP
core)
Reserved RO 0x00
23:16
(half-
width IP
core)
WordLock
RO 0x00
Each bit indicates whether the corresponding
transceiver channel in the HMC link has locked to
the TS1 word boundary.
31:16
(full-
width IP
core)
WordLock
RO 0x0000
15:8
(half-
width IP
core)
Reserved RO 0x00
