Doc #: L-802-1110 Page 42 Rev. 02
4 CONFIGURATION
4.1 Turning the Tonnage Monitor ON in Device Config
Before anything can be configured on the tonnage monitor, the operator terminal must be made aware
that it is connected and how many channels will be used. To do this, press the ACC key on the keypad
to bring up the “Quick Access” screen. With the RUN/PROG key in the PROG position, the lower left
hand softkey should show as DEVICE CONFIG. Press this softkey and enter the system configuration
code to gain access to the Device Config screen. This screen contains a list of the options that can be
used with the operator terminal. The option name for the tonnage monitor is “Tonnage & Analog Sig.
Monitor”. This option will usually not be on the first page so press the NEXT PAGE softkey until it is
visible. The screen should look similar to Figure 14.
Stroke
Mode Single Stroke
Drive
Speed
Stroke
Speed
SPM
SPM
0
0 Order
Counter
Current Status
Counter OFF
EXIT
0 0
Program/Run Switch
TOP
Device
Config
Auto Setup Mod. 1
Device Configuration
Yes TOGGLE
USED
Device Used
Auto Setup Mod. 2
Auto Setup Mod. 3
Auto Setup Mod. 4 No
No
No
Tonnage & Analog Sig. Monitor Yes
UPDATE
FIRMWARE
DEVICE
INFO
DIAGNOSTIC
COUNTERS
PREVIOUS
PAGE
CONFIGURE
OPTION
Stroke
Mode Single Stroke
Drive
Speed
Stroke
Speed
SPM
SPM
0
0 Order
Counter
Current Status
Counter OFF
EXIT
0 0
Program/Run Switch
TOP
Device
Config
Auto Setup Mod. 1
Device Configuration
Yes TOGGLE
USED
Device Used
Auto Setup Mod. 2
Auto Setup Mod. 3
Auto Setup Mod. 4 No
No
No
Tonnage & Analog Sig. Monitor Yes
UPDATE
FIRMWARE
DEVICE
INFO
DIAGNOSTIC
COUNTERS
PREVIOUS
PAGE
CONFIGURE
OPTION
Figure 14: Device Config Screen
Using the arrow keys, highlight “Tonnage & Analog Sig. Monitor”. If the “Used” column by the
tonnage monitor does not already say “Yes”, press the TOGGLE USED softkey to change it.
4.2 Setting the Number of Channels
While the tonnage monitor is highlighted in the Device Config screen of Figure 14, the CONFIGURE
OPTION softkey (just to the left of EXIT) should appear. Press this key to bring up the Tonnage
Monitor Device Configuration screen as shown in Figure 15.
