Doc #: L-802-1110 Page 38 Rev. 02
Store As Reference The OmniLink II OIT can store one “reference” tonnage waveform per job.
This reference waveform can be overlaid with the current waveform to make a
direct on-screen comparison of the two. The “Store As Reference” selection of
the SEND GRAPH softkey will retrieve the tonnage waveform from the
tonnage monitor, make a reference waveform from it, and store it under the
current job number. Note that this operation is a restricted operation and may
require the RUN/PROG key and/or an access code depending on system
configuration (see section 11 on page 78 for details). After success or failure is
reported, press any key to resume normal operation of the screen.
Send To Laptop This option is only available if the laptop interface has been set up in auxiliary
communications. In addition, a computer with the Link Graphical Tonnage
Analyzer must be connected to the laptop port for this operation to succeed.
When the “Send To Laptop” option of the SEND GRAPH softkey is selected,
the OmniLink will retrieve the tonnage waveform from the tonnage monitor
and transfer it to the laptop. After success or failure is reported, press any key
to resume normal operation of the screen.
Send To Network This option is only available if the LinkNet interface has been set up in
auxiliary communications and the network is “online”. When the “Send To
Network” option of the SEND GRAPH softkey is selected, the OmniLink will
retrieve the tonnage waveform from the tonnage monitor and transfer it to the
network host computer. This will result in the tonnage waveform being shown
in a window on the LinkNet host computer. The waveform can then be printed,
archived, or deleted as desired. After success or failure is reported, press any
key to resume normal operation of the screen.
Archive To Network This option is only available if the LinkNet interface has been set up in
auxiliary communications and the network is “online”. When the “Archive To
Network” option of the SEND GRAPH softkey is selected, the OmniLink will
retrieve the tonnage waveform from the tonnage monitor and transfer it to the
network host computer. This will result in the tonnage waveform being
automatically archived into the waveform database on the LinkNet host
computer. After success or failure is reported, press any key to resume normal
operation of the screen. Note that this operation is a restricted operation and
may require the RUN/PROG key and/or an access code depending on system
configuration (see section 11 on page 78 for details).
