4 configuration, 1 turning the tonnage monitor on in device config, 2 setting the number of channels – LINK Systems 5100-8 Tonnage & Analog Signal Monitor User Manual
Page 43: Turning the tonnage monitor on in device config, Setting the number of channels, Figure 14: device config screen

Doc
#:
L-802-1110 Page
41 Rev.
02
Graph Acquisition
Press Speed
For normal operation, set this value to 0. For presses that slow or stop at the
bottom of the stroke, set this somewhat slower than the actual press speed. It
may require some trial and error to find the right value. If the waveform runs
out of points (4096 points shown on the graph screen), then lower this value. If
the number of points captures is less than 2000, then raise this value. The ideal
setting would result in just short of 4096 captured points.
Graph Slow Sample
Threshold Speed
This sets the press speed at which the tonnage monitor switches to the slow
graph storage sample rate.
