4. PBX Systems
data sent to the display. Refer to the Dialogic ® PBX Integration Software
Reference for more information about using d42_gtcallid( ) function.
The contents of the called/calling number ID are shown in Table 22 (as seen
by the receiver of the call).
Table 22. Called/Calling Number ID Data for the Mitel Superset
Call Route Example Display
(Soft Key not Shown) Called/
Calling No.
ID Data
Call received
from trunk “T001 “
“T102 IS CALLING”
“X154 IS CALLING” _0-001
_0-012
_0-154
Call received
from station set
221 “221 IS CALLING “ _221
Call originally
received on trunk,
then transferred to
station set 2103 “T002 FORWARDED
FROM 2103 NO A” 2103_0-002
Call originally
received by
extension 2103,
then forwarded to
extension 2104 “2104 IS CALLING
FORWARDED FROM 2103 NO A” 2103_2104
External direct
call with the word
EXTERNAL “EXTERNAL IS CALLING ” _
External
forwarded call
with the word
EXTERNAL “EXTERNAL CALL FWD
FROM 1778 RICK NO ANS” 1778_
99
