4. PBX Systems
Table 15. Mitel Superset 420/430 LCD Line Indicator States
State Value (Hex)
Off 0x00
On 0x01
Ringing 0x02
Hold 0x03
Error 0x04
Unknown 0x05
Reading LCD Line Indicators
The Dialogic
®
PBX Integration Board can determine the state of its Line
Indicators by using the d42_indicators( ) function to retrieve the LCD
Indicators data. This function places the Line Indicator data (12 bytes) in an
application buffer. Bytes 0-11 contain the indicator status for Feature Keys 00-
11, respectively (see
Table 16 and Table 17 ).
Table 16. Mitel Superset 420 LCD Line Indicators (with SX-50) and
Dial Strings
Byte Key Description Dial String
00 Personal Key 00 KA
01 Personal Key 01 KB
02 Personal Key 02 - Message Waiting KC
03 Personal Key 03 KD
04 Personal Key 04 KE
05 Personal Key 05 KF
06 Personal Key 06 KG
07 Personal Key 07 KH
08 Personal Key 08 KI
09 Personal Key 09 KJ
