4. PBX Systems

General Call

Consultation

Programmable

Line

MWL_OFF

Mailbox

Callback

Indicators

Feature Keys

Display

Programmable

MWL_ON

Figure 6. Siemens Optiset E Telephone with the Hicom 300

4.3.3. Programmable Feature Keys

As illustrated in

Figure 5

and

Figure 6

, there are 12 Programmable Feature

Keys located below the display on the Optiset E telephone. These keys can be
configured either during PBX installation or by the user (using the telephone
set or the Dialogic

PBX Integration Board). There is an LED indicator
