PBX Integration Board User’s Guide
Table 25. M7324 LCD Indicator States
State Value (Hex)
off 0x00
on 0x01
ringing 0x02
hold 0x03
error 0x04
unknown 0x05
Reading LCD Indicators
The Dialogic ® PBX Integration Board can determine the state of its LCD
indicators by using the d42_indicators( ) function to retrieve the LCD
indicators data. This function places the Line Indicator data in an application
buffer. For a M7324, bytes 0-23 contain the indicator status for Memory Keys
00-23, respectively (see
Table 26 ).
Table 26. M7324 Direct Key Dialing Strings for Memory Keys
Byte Key Description Dial String
00 Memory Button 00 K0
01 Memory Button 01 K1
02 Memory Button 02 K2
03 Memory Button 03 K3
04 Memory Button 04 K4
05 Memory Button 05 K5
06 Memory Button 06 K6
07 Memory Button 07 K7
08 Memory Button 08 K8
09 Memory Button 09 K9
10 Memory Button 10 KS
