Line Key 1
00 0F 00 00 00 00 00 00 00 00 00 00 00 00 00 00 xx 00 00 00 xx 00 00 00
00 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20 21 22 23
00 00 xx xx xx xx xx xx xx xx xx xx xx xx xx xx xx xx xx xx xx xx xx xx
24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47
Line Key 2 Line Key 3 Line Key 4 Line Key 5 Line Key 6 Line Key 7 Line Key 8 Line Key 9 Line Key 10 Line Key 1
1
Line Key 12 Line Key 13 Line Key 14 Line Key 15 Line Key 16 Not Used MWI CNF Key FCN Key Not Used LNR/SPD Key ANS Key SPKR Key
Data
Byte
Data
Byte
ICM MIC
NOTE: Bit 3 determines if the indicator is red or green. If bit 3 is 0, the
indicator is red; if bit 3 is 1, the indicator is green.
The example below shows the binary data for On and Wink.
Bit Hex 7 6 5 4 3 2 1 0
On 0x7 (red) 0 1 1 1 x x x x
On 0xF (green) 1 1 1 1 x x x x
Wink 0x2 (red) 0 0 1 0 x x x x
Wink 0xA (green) 1 0 1 0 x x x x
Pressing Flexible Line Keys
The Dialogic ® PBX Integration Board can “press” any of its Flexible Line
keys using the dx_dial( ) function. Refer to the Dialogic
®
PBX Integration
Software Reference for more information about dialing keys. Each Flexible
Line key on the DTerm Series III telephone is assigned a dial string sequence
(refer to
Table 36 ). By using the dx_dial( ) function and the appropriate dial
string, the PBX Integration Board can press any Flexible Line key.
