PBX Integration Board User’s Guide
Table 20. Mitel Superset 420 Direct Key Dialing Strings for Display
Keys
Dial String Key Description Display (Soft) Key #
Ka Left Softkey Display key 00
Kb Middle Softkey Display key 01
Kc Right Softkey Display key 02
Table 21. Mitel Superset 430 Direct Key Dialing Strings for Display
Keys
Dial String Key Description Display (Soft) Key #
Ka Top Left Softkey Display key 00
Kb Top Middle Softkey Display key 01
Kc Top Right Softkey Display key 02
Kd Bottom Left Softkey Display key 03
Ke Bottom Middle Softkey Display key 04
Kf Bottom Right Softkey Display key 05
4.4.6. Alphanumeric Display
The alphanumeric display is a:
• 160-digit LCD on Mitel Superset 430 phones
• 32-digit LCD on Mitel Superset 420 phones
The LCD is used to show:
• date and time when the extension is idle
• SuperKey instructions and Softkey labels during programming and
feature access
• call status
• messaging information
• telephone system error messages
• saved numbers (speed dialing)
