4.5.3. Using the Dialogic

PBX Integration Board

The Dialogic

PBX Integration Board performs functions available to a

M7324 telephone set (see

Figure 12

). An M7324 telephone set uses three

LCD displays. Two are used to show key status indicators (between the line
keys), while the other display is used for user prompts and messages (above
the display keys). The PBX Integration Board can:

• transfer calls

• set the message waiting indicator

• read the LCD display

• read LCD indicators

• read the called/calling number ID

• press keys
