4. PBX Systems
Table 36. DTerm Series III Direct Key Dialing Strings for Feature
Keys
Byte Key Description Dial String
00 Flexible Line Key 1 KW
01 Flexible Line Key 2 KX
02 Flexible Line Key 3 KY
03 Flexible Line Key 4 KZ
04 Flexible Line Key 5 Ka
05 Flexible Line Key 6 Kb
06 Flexible Line Key 7 Kc
07 Flexible Line Key 8 Kd
08 Flexible Line Key 9 Ke
09 Flexible Line Key 10 Kf
10 Flexible Line Key 11 Kg
11 Flexible Line Key 12 Kh
12 Flexible Line Key 13 Ki
13 Flexible Line Key 14 Kj
14 Flexible Line Key 15 Kk
15 Flexible Line Key 16 Kl
Example
An application uses the d42_indicators( ) function to retrieve the current data
for the LCD indicators on a given channel on a Dialogic
® PBX Integration
Board. The data placed in the application buffer is shown below. If the data
for byte 1 is 0x0F, the indicator for Flexible Line key 2 is green and on. Refer
to the Dialogic
® PBX Integration Software Reference for more information
about using the d42_indicators( ) function.
155
