The contents of the called/calling number ID (as seen by the receiver of the
call) are shown in

Nortel BCM).

Table 28. Called/Calling Number ID Data for the Nortel Norstar

Call Route

Called/Calling Number ID Data

Call received from trunk line 1

_0-1

Call received from station set 221

_221

Call originally received on trunk line 1,
then transferred to station set 223

223_0-1

Extension 224 has its calls forwarded to
a D82 port. Digital set 221 calls 224. The
D82 port displays the given CPID.

224_221

NOTES: 1.

Dialogic

PBX Integration Boards extract the called/caller ID

information from the protocol packets, not by parsing the display.

2. The display is parsed only for Answer DN calls. For these calls,

the protocol information is not considered.

Table 29. Called/Calling Number ID Data for the Nortel BCM

Call Route

Called/Calling Number ID Data

Call received from trunk line 1

_7165551234

Call received from station set 2221

_2221

Call originally received from a trunk line
is answered by the station set 2221, and
the call is transferred to a D82 port

2221_165551234

Station set 2224 has its calls forwarded
to a D82 port. The station set 2221 calls
x2224. The CPID returned on the D82
port is given.

2224_2221
