7-6
pH & mV MODE
7.1.2.5 Graph Standardization Data
Graphs the electrode standardization data (pH vs mV).
7.1.2.6 pH Standardization Data
Displays the electrode standardization data in a tabular form.
7.1.2.7 Resolution
You can choose between 0.1, 0.01 and 0.001 resolution for the displaying pH values.
7.2
mV Mode
7.2.1
Display
The mV screen shown below will help you understand the following discussion.
mV Mode Option Keys:
Brings you to the General Options screen (for more details, see Chapter 4
General Options).
Stores the current mV reading (see section 7.3.2 Manual logging).
Displays the setup options for mV (see section 7.2.2 mV Menu).
Switches to the pH screen.
Return to the main screen.
mV Value
Time and Date
Temperature
Compensation
Status
Status Bar
Temperature
Readings
Logging
mV Units
Stirrer
Reading
mV Readings
Information
and Mode
Information
Status
and Units
