Ph & mv mode, 7ph & mv mode – Hanna Instruments HI 901 User Manual
Page 93
7-3
pH & mV MODE
7
pH & mV MODE
The HI 901 / HI 902 titrators can be used to log precise pH or mV measurements.
By pressing
from the main screen, the titrator will switch to the pH or mV screen
(depending on the End Point Mode option selected from View / Modify Method screen).
7.1
pH Mode
7.1.1
Display
The pH screen shown below will help you understand the following explanations.
pH Mode Option keys:
Brings you to the General Options screen (for more details, see Chapter 4
General Options).
Stores the current pH reading (see section 7.3.2 Manual logging).
Displays the setup options for pH (see section 7.1.2 pH Menu).
Switches to the mV screen.
Return to the main screen.
Temperature
Source
Time and Date
pH Value
Status Bar
Temperature
Readings
