Storage Devices, Mouse, Audio & Printer
Audio Features 2 - 13
2
Setup for 5.1 Surround Sound
To setup your system for 5.1 surround sound you will need to connect the audio ca-
bles to the Line-In and Microphone-In jacks.
1.
Click Start, and click Control Panel (or point to Settings and click Control Panel)
and make sure you are in Classic View.
2.
Click Realtek HD Audio Manager (or right-click the taskbar icon
and select
Sound Manager).
3.
Click Speakers (tab) and click Speaker Configuration (tab).
4.
Select 5.1 Speaker from the Speaker Configuration pull-down menu.
Figure 2 - 11
Speaker
Configuration
Auto Popup Dialog
You should enable the
auto popup dialog to au-
tomatically detect when a
device has been
plugged-in. If disabled,
double-click connector
settings
and click the
box to enable the auto
popup detection of
plugged-n devices.
Connector Settings
