7 - 38 Setting Up SATA RAID or AHCI Modes
7
RAID Setup (Intel Matrix)
1. Press Ctrl + i to enter RAID configuration menu.
2. Select 1.Create RAID Volume and press Enter.
3. Type the RAID volume name and then press Tab or Enter to advance to the next
field.
4. Specify (use the up and down arrow keys) the RAID level (RAID 0 or RAID 1 or
Recovery - see
Table 7 - 1, on page 7 - 36 ) and then press Tab or Enter to
advance to the next field.
5. Press Enter and the system will select the physical disks to use.
6. Press Enter and select (if applicable) the Strip Size (best set to default).
7. Press Enter and select the Capacity size (best set to default).
8. Press Enter to select Create Volume.
9. Press Enter to create the volume, and confirm the selection by pressing Y.
RAID Volumes: * = Data is Encrypted
None Defined
Physical Disks:
Port Drive Model
Serial # Size Type/Status(Vol ID)
0 FUJITSU MHY2120B K404T812P22B 111.7GB Non-RAID Disk
1 FUJITSU MHY2120B K404T7C2KJ14 111.7GB Non-RAID Disk
Intel(R) Matrix Storage Manager option ROM v8.5.0.1030 ICH10R wRAID5
Copyright (C) 2003-08 Intel Corporation. All Rights Reserved.
[ MAIN MENU ]
[ DISK/VOLUME INFORMATION ]
[ ] - Select [ESC]-Exit [ENTER]-Select Menu
1. Create RAID Volume 3. Reset Disks to Non-RAID
2. Delete RAID Volume 4. Recovery Volume Options
5. Exit
Figure 7 - 29
Intel(R) Matrix
Storage Manager
Option ROM
Recovery Level
When selecting disks for
the Recovery RAID level
you will need to use the
Tab key to select a Mas-
ter disk, and the Space
key to select a Recov-
ery disk.
You can select the syn-
chronization between
the disks to be Continu-
ous (automatic) or On
Request (manually).
