Upgrading The Computer
Upgrading the System Memory (RAM) 6 - 9
6
6. Fully loosen screws - in the order indicated here (and on the label).
7. Disconnect cable .
8. Carefully (make sure all the screws are sufficiently loosened and cables
disconnected) remove the heat sink and fan unit
.
17 23
24
Figure 6 - 7
Heat Sink
Removal
Caution
The heat sink, and
CPU area in general,
contains parts which
are subject to high
temperatures. Allow
the area time to cool
before removing these
parts.
25
22
17 18
19 20
21 23
24
25
