Upgrading The Computer
Upgrading the System Memory (RAM) 6 - 11
6
Upgrading a Third System Memory (RAM) Module
If you wish to add a third memory module follow the procedure below (note the side-
bar warning on RAM speeds).
1. Turn off the computer, and turn it over and remove the battery.
2. Turn the computer back over to access the keyboard.
3. Press the four keyboard latches - at the top of the keyboard to elevate the
keyboard from its normal position (you may need to use a small screwdriver or pair
of tweezers to do this).
RAM Module Speeds
Use either 1066MHz OR
1333MHz DDRIII
(DDR3) modules of the
same brand. Do not mix
DRAM speeds/brands in
order to prevent unex-
pected system behavior.
Figure 6 - 9
Keyboard Latches
1 4
1 3 2 4
