System Map: Right & Bottom Views 1 - 15
Quick Start Guide
1
System Map: Right & Bottom Views
Figure 1 - 8
Right & Bottom
Views
1.
USB Ports
2.
Security Lock
Slot
3.
Fan Outlet/Intake
4.
Battery
(Secondary HDD
Bay - HDD3)
5.
Primary HDD
Bay (HDD1 & 2)
6.
Component Bay
Cover
Overheating
To prevent your comput-
er from overheating
make sure nothing
blocks the vent(s)/fan in-
take(s) while the com-
puter is in use.
1
1
2
4
3
3
3
3
5
6
Battery Information
Always completely dis-
charge, then fully charge, a
new battery before using it.
Completely discharge and
charge the battery at least
once every 30 days or after
about 20 partial discharges.
See
for full in-
structions.
