Modules
Setting Up SATA RAID or AHCI Modes 7 - 39
7
10. This will now return to the main menu.
11. Select 5.Exit and press Enter, then press Y to exit the RAID configuration menu.
12. As the computer starts up, press a key when you see the message "Press any
key to boot from CD".
13. Press Enter to continue installing the operating system as normal (see your
Windows documentation if you need help on installing the Windows OS).
14. If you have selected a Recovery level RAID then see “Windows Installation for
Recovery Level RAID Systems” on page 7 - 40 .
15. Install the Windows drivers from the Device Drivers & Utilities + User’s Manual
disc as per Table 4 - 1, on page 4 - 3 (make sure you install the Intel Matrix driver
- see “Intel® Matrix Driver Installation” on page 7 - 42 ).
Figure 7 - 30
RAID Created
RAID Volumes: * = Data is Encrypted
ID Name Level Strip Size Status Bootable
0 MyRAID RAID1(Mirror) N/A 111.7GB Normal Yes
Physical Disks:
Port Drive Model
Serial # Size Type/Status(Vol ID)
0 FUJITSU MHY2120B K404T812P22B 111.7GB Member Disk(0)
1 FUJITSU MHY2120B K404T7C2KJ14 111.7GB Member Disk(0)
Intel(R) Matrix Storage Manager option ROM v8.5.0.1030 ICH10R wRAID5
Copyright (C) 2003-08 Intel Corporation. All Rights Reserved.
[ MAIN MENU ]
[ DISK/VOLUME INFORMATION ]
[ ] - Select [ESC]-Exit [ENTER]-Select Menu
1. Create RAID Volume 3. Reset Disks to Non-RAID
2. Delete RAID Volume 4. Recovery Volume Options
5.Exit
