System Map: LCD Panel Open 1 - 7
1
System Map: LCD Panel Open
Figure 1 - 3
LCD Panel Open
1. Optional Built-In
PC Camera
2. LCD
3. LED Power &
Communication
Indicators
4. Built-In
Microphone
5. LED Status
Indicators
6. Hot Key Buttons
7. Power Button
8. Keyboard
9. Speakers
10. Game Hot Keys
11. Touchpad &
Buttons
See Appendix A for a more
detailed description of the
ports & jacks etc.
2
1
6
9
7
4
3
Wireless Device Operation
Aboard Aircraft
The use of any portable electronic
transmission devices (e.g. WLAN or
Bluetooth) aboard aircraft is usually
prohibited. Make sure any wireless
modules are OFF if you are using
the computer aboard aircraft.
Use the appropriate function key
combination (see
Table 1 - 4, on
page 1 - 11 ) to toggle power to any
wireless modules, and check the
LED indicators to see if any modules
are powered on or not (see
Table 1
- 2, on page 1 - 8 ).
9
11
5
8 10
3
