Interface (Ports & Jacks)
A - 2 Interface (Ports & Jacks)
A
Ports and Jacks
Item Description
Card Reader The card reader allows you to use the following digital storage cards:
MMC (MultiMedia Card) RS MMC (requires PC adapter)
SD (Secure Digital) Mini SD (requires PC adapter)
MS (Memory Stick) MS Duo (requires PC adapter)
MS (Memory Stick Pro)
Cable (CATV)
Antenna Jack
Use this jack to connect a CATV cable if you have included the optional TV Tuner in your
purchase.
Consumer Infrared
Transceiver
The consumer infrared transceiver at the front of the computer allows the computer to
communicate with the remote control unit supplied with the optional TV Tuner.
DC-In Jack Plug the supplied AC/DC adapter into this jack to power your computer.
DVI-Out Port The DVI-Out (Digital Visual Interface) Port (at the rear of the computer) allows you to connect an
external monitor, or Flat Panel Display, to allow dual video or simultaneous display on the LCD
and external monitor/FPD
(see “Display Devices” on page B - 5 ). If you are using an older type
of monitor you will need to use a converter to convert the signal from DVI to VGA.
e-SATA Port Plug external Serial ATA hard drives into this e-SATA (external Serial Advanced Technology
Attachment) port. Install the Intel Matrix Storage driver to display the safe removal icon for e-
SATA devices in the taskbar (see
“Intel® Matrix Driver Installation” on page 7 - 42 ).
e-SATA
